Sustainable RFID MIFARE® DESFire® EV3 2K / 4K/ 8K Card
SizeCR80--85.5*54mm (Be customized)
CraftGlossy, Matte, Matte, Epoxy (Single or Double), Brushed (Single or Double), Laser (Single or Double)
Thickness0.76mm / 0.84mm / or be customized
MaterialRPVC/PLA/PC/PET/PETG/PBAT/TESLIN
Printing methodLaser code, flat code (gold flat code, white flat code, black flat code), inkjet code (ordinary inkjet code, UV inkjet code), embossed code (gold embossed code, silver embossed code), barcode (one-dimensional barcode, two-dimensional code barcode), QR code
RF InterfaceISO/IEC 14443-2, Type A 13.56 MHz
Chips
NXP MIFARE® DESFire® EV3 2K (17PF or 70PF) (D23)
NXP MIFARE® DESFire® EV3 4K (17PF or 70PF) (D43)
NXP MIFARE® DESFire® EV3 8K (17PF or 70PF) (D83)
NXP MIFARE® DESFire® EV3 16K
NXP MIFARE® DESFire® EV3 32K
The MIFARE® DESFire® family consists of various contactless ICs and are suited for solution developers and system operators building reliable, interoperable and scalable contactless solutions. It targets multi-application smart card solutions in identity, access, loyalty and micro-payment applications as well as in transport schemes. MIFARE DESFire products fulfill the requirements for fast and highly secure data transmission, flexible memory organization and is interoperable with existing contactless infrastructures.
Airport luggage tag
Crusie / Ferry
More applications
More applications
More applications
Gym / Tennis
Skydiving / Goft
Why choose us?
Key applications and Key features
Public transportation
Access management
Closed-loop micropayment
Campus and student ID cards
Loyalty programs

Flexible file structure hosts as many applications as memory size supports
NFC Forum Tag Type 4 compliant
SUN (Secure Unique NFC) message authentication for advanced data protection
Card generated MAC to authenticate transactions
Transaction Timer defends against man-in-the-middle attacks
CE & Exhibition
Amusement park/Water park
Eat & Drink & Entertain ( all in one card)
Ski day pass card
Baseball
Introduction to Sustainable RFID MIFARE® DESFire® EV3 4K card
The features of the MIFARE® DESFire® EV3 IC reflect NXP’s continued commitment to secure, connected and convenient Smart City services. As part of the MIFARE DESFire family, the latest IC brings enhanced performance with a greater operating distance and improved transaction speed compared to its predecessors.

An extensive list of security features give MIFARE DESFire EV3 more ways to protect data and help ensure privacy. The IC hardware and software are certified to Common Criteria EAL 5+, and the IC supports a broad choice of open crypto algorithms based on DES, 2K3DES, 3K3DES, or AES. A new Transaction Timer feature, which can be used to set a maximum time per transaction, helps mitigate man-in-the-middle attacks.

Smart City services that run on a MIFARE DESFire EV3 IC can be deployed to NFC smartphones and wearables using NXP’s MIFARE 2GO cloud service, which manages digitized MIFARE product-based credentials and can enable contactless payments or access features using NFC-enabled devices.
FAQ
Optional materials
PVC/PET/PETG/PLA/PBAT/RPVC/WOODEN/TESLIN/PC
