Sustainable RFID MIFARE Ultralight® EV1 card

SizeCR80--85.5*54mm (Be customized)

CraftGlossy, Matte, Matte, Epoxy (Single or Double), Brushed (Single or Double), Laser (Single or Double)

Thickness0.76mm / 0.84mm / or be customized

MaterialRPVC/PLA/PC/PET/PETG/PBAT/TESLIN

Printing methodLaser code, flat code (gold flat code, white flat code, black flat code), inkjet code (ordinary inkjet code, UV inkjet code), embossed code (gold embossed code, silver embossed code), barcode (one-dimensional barcode, two-dimensional code barcode), QR code

Frequency13.56MHz

Chips
NXP MIFARE Ultralight® EV1
(48bytes or 128bytes)

MIFARE Ultralight EV1 is the next generation of paper ticketing smart card IC for limited-use applications that offers solution developers and operators the maximum flexibility for their ticketing schemes and additional security options. Enabling easy integration in existing infrastructures is guaranteed by compatibility with MIFARE based systems. The integrated originality checker is an effective cloning protection that helps to prevent counterfeit of tickets.

Crusie / Ferry

Gym / Tennis

Skydiving / Goft

Airport luggage tag

More applications

Ski day pass card

Baseball

Key applications of Sustainable RFID MIFARE Ultralight® EV1 card

Public transportation
Event ticketing
Loyalty

Key applications of Sustainable RFID MIFARE Ultralight® EV1 card

Limited-use tickets in public transport
Event ticketing (stadiums, exhibitions, leisure parks, etc.)
Loyalty

Key features of Sustainable RFID MIFARE Ultralight® EV1 card

Fully ISO / IEC 14443 A 1-3 compliant
Backwards compatible to MIFARE Ultralight
106 kbit/s communication speed
Anti-collision support
Fast read command
384 and 1024 Bits user memory product variants
OTP, Lock Bits, configurable counters
Three independent 24-bit one-way counters
Protected data access through 32-bit password
Preparation for Virtual Card functionality
Unique 7 bytes serial number
Number of single write operations: 10,000

Benefits for solution developers

Compliance to ISO/IEC 14443 A 1-3
NFC Forum Type 2 Tag compliant
Backwards compatibility to MIFARE Ultralight
Limited integration effort in MIFARE DESFire product-based solutions
Enhanced security for limited-use applications
Fast time-to-market

Why choose us?

Amusement park/Water park
Eat & Drink & Entertain ( all in one card)

CE & Exhibition

Security of Sustainable RFID MIFARE Ultralight® EV1 card

Manufacturer programmed 7-byte UID for each device
32-bit user definable One-Time Programmable (OTP) area
3 independent 24-bit one-way counters
Field programmable read-only locking function per page (per 2 pages for the extended memory section)
ECC-based originality signature
32-bit password protection to prevent unintended memory operations
